Beskrivning
Data transmission
- Jumbo frames support Yes
- Latency (1 Gbps) 2 ps
- Latency (10-100 Mbps) 7 ps
- MAC address table 8000 poster
- Packet buffer memory 1,5 MB
- Switching capacity 52 Gbit/s
- Throughput 38,6 Mpps
Design
- Energy Star certified Yes
- Form factor 1U
- Product colour Grey
- Rack mounting Yes
- Stackable Yes
Logistics data
- Harmonized System (HS) code 85176990
Management features
- Quality of Service (QoS) support. Yes
- Switch layer L2
- Switch type Managed
- Web-based management Yes
Network
- 10G support No
- Auto MDI/MDI-X Yes
- Copper ethernet cabling technology 1000BASE-T/100BASE-TX/10BASE-T
- Flow control support Yes
- Full duplex Yes
- Link aggregation Yes
- Networking standards IEEE 802.3/IEEE 802.3ab/IEEE 802.3u
- Port mirroring Yes
- Spanning tree protocol Yes
- VLAN support Yes
Operational conditions
- Operating relative humidity (H-H) 15 – 95 %
- Operating temperature (T-T) 0 – 40 °C
- Storage relative humidity (H-H) 15 – 95 %
- Storage temperature (T-T) -40 – 70 °C
Performance
- Built-in processor Yes
- Flash memory 16 MB
- Harmonized System (HS) code 85176990
- Internal memory 128 MB
- Memory type SDRAM
- Processor frequency 400 MHz
- Processor model ARM Cortex-A9
Ports & interfaces
- Basic switching RJ-45 Ethernet ports quantity 24
- Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
- SFP module slots quantity 2
Power
- AC input frequency 50 – 60 Hz
- AC input voltage 100 – 240 V
- Power consumption (typical) 22 Watt
- Power supply included Yes
- Power over Ethernet (PoE) No
Product dimensions
- Net Weight (Product, kg) 2,7 kg
- Product Depth 24,61 cm
- Product Height 4,39 cm
- Product Width 44,25 cm
Security
- DHCP features DHCP client
- IGMP snooping Yes
- SSH/SSL support Yes
Garanti 1 år
Lagerplats K2
